Back to SmartLok

SmartLok Shoring & Double Decking

Full utilisation of light commercial vehicle capacity

The SmartLok Shoring Poles and Beams are compatible with the full range of SmartLok products, including Combi Pole and Tracks.

Request quotation Contact us

The SmartLok Shoring Poles and Beams are compatible with the full range of SmartLok products, including Combi Pole and Tracks. Together they form a flexible system for load securing and optimizing the space of LCV’s. Simply plug and play to create a system that works best for you.

38 Years of experience

We've been around in cargo control for a long time

Customisations

We're able to customize to your requirements

European Manufacturer

We design and manufacture in Europe

LCV in Logistics

The transport landscape is changing. The distribution model is shifting from bulk transport in trucks to a combination of train and trucks between large hubs close to large cities. Smaller vehicles (LCV) take care of the final distribution inside city centres.

Last Mile Logistics

Once the central distribution has been done, it then has be transported to the final destination. As this last leg of distribution is often less-efficient, comprising up to 53% of the total cost to move goods. We saw the ‘last mile problem’ as our challenge to create a solution that is as dynamic and flexible it can be. We introduced SmartLok – a range of smart plug & play products to create a flexible system for LCV. Create a second floor in an instant, use a combination of straps and fittings, or secure longitude items with shoring poles in combination with customizable tracks.

LCV in Pharma /Multitemp Logistics

Keeping the cold chain intact can be difficult, especially in last mile pharma or multitemp logistics. By optimizing the loading space the operator has better control of the temperature. Our SmartLok Tempwall60 Van has been optimized for LCV. Completely customizable and comes standard with the most optimum closure to prevent cold air leakage. Including specific including foldable corner flaps which are designed to accommodate the wheel arches to ensure a robust seal.

SmartLok Shoring Pole

With the SmartLok Shoring Poles it becomes easy to keep cargo in place in the LCV. The SmartLok Shoring Poles are easily adjustable in length and therefore fit between the tracks.The shoring poles are also very convenient for clamping longitudinal goods such as doors or plates to prevent them from falling over when taking a turn. In an instant, the aluminium shoring pole is positioned (horizontally or vertically) between the SmartLok Rails or Combi Poles.

Due to the multiplugs, it is also possible to fit the pole in any other type of rail. With an adjustable range they fit in almost every van! Flexibility to the max.

SmartLok Shoring Pole

Article no.	Category	Type	Material	Finishing	Working Range (mm)	Outer Tube Size (mm)	Plug Diameter (mm)	Load Capacity (daN)
10012442	Adjustable	Round	Aluminum	Anodised	1160 - 1760	37 x 3	19/24 Multiplug	350
10012443	Adjustable	Round	Aluminum	Anodised	1700 - 2300	37 x 3	19/24 Multiplug	350
Custom	Adjustable	Round	Aluminum	Non-Anodised Anodised	Customizable	37 x 3	19 24 Multiplug	350

_{< Scroll left to right >}
_{Minimum order quantities apply, please ask our sales department}

> Product Catalog

SmartLok Double Decking

With our compatible system of Combi Poles, Tracks and Beams it becomes easy to create a second floor inside any LCV. Specifically designed to optimize the space, for example for non-stackable goods. Position the Combi Poles over the length of the vehicle, connected to the SmartLok Rails (fully recessed, semi-recessed or surface mounted). With the SmartLok Beams you can either be used to create a decking surface or for shoring.

SmartLok Combi Pole

Article no.	Type	Product	Material	Finishing	Working Range (mm)	Outer Tube Size (mm)	Plug Diameter (mm)	Load Capacity (daN)
10013316	Squared	SmartLok	Aluminum	Non-Anodised	1050 - 1350	52 x 52	19/24 Multiplug	350
10013321	Squared	SmartLok	Aluminum	Non-Anodised	1300 - 1600	52 x 52	19/24 Multiplug	350
10013317	Squared	SmartLok	Aluminum	Non-Anodised	1550 - 1850	52 x 52	19/24 Multiplug	350
10013322	Squared	SmartLok	Aluminum	Non-Anodised	1800 - 2100	52 x 52	19/24 Multiplug	350
Custom	Squared	SmartLok	Aluminum	Non-Anodised Anodised	Customizable	52 x 52	19 24 Multiplug	350

_{< Scroll left to right >}
_{Minimum order quantities apply, please ask our sales department}

> Product Catalog

SmartLok Beams

Article no.	Material	Finishing	Working Range (mm)	Load Capacity Decking (daN)	Load Capacity Shoring (daN)
10013314	Aluminum	Non-Anodised	800 - 1000	300	300
10013315	Aluminum	Non-Anodised	1250 - 1750	300	300
10013320	Aluminum	Non-Anodised	950 - 1300	300	300
Custom	Aluminum	Non-Anodised Anodised	Customizable	300	300
